P3.91 Outdoor LED Panel Video Wall Display With Aluminum Alloy Cabinet
Product Details:
| Place of Origin: | China |
| Brand Name: | Charming |
| Certification: | CE, ROHS, LVD, EMC, CB, BIS, UL |
| Model Number: | U23-C100 LED Pixel Bar |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton Case,Wooden Case, Fight Case |
| Delivery Time: | 10 Working Days after Payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 PCS per month |
|
Detail Information |
|||
| Type Number: | R391W-1000H Type | Dimension(MM): | 500×1000×85 |
|---|---|---|---|
| Cabinet Weight(KG): | 13.2KG Weight | Refresh Rate（Hz）: | 3840 / 1920Hz |
| Pixel Pitch(MM): | P3.91mm | LED Standard: | Smd1921 |
| Scan Mode: | 1/16 Scan | Pixel Density(Dot/㎡): | 65536 Dot/㎡ |
| Brightness（CD/㎡）: | 4600 CD/㎡ | Viewing Angle: | 125° |
| Protection Level: | IP65 | Cabinet Material: | Aluminum Alloy |
| Maintenance Method: | Front Maintenance | Grey Level: | 12-16 Bit |
| Working Temperature: | -10~6 | Working Humidity: | 10-90% |
| Life Span: | ＞50000 Hour | Working Voltage: | AC 110V/220V,50/60Hz |
| Highlight: | P3.91 Outdoor LED Panel Video Wall,Aluminum Alloy LED Panel Video Wall |
||
Product Description
Top Selling Led Panel Video Wall Screen P3.91 Outdoor Led With Video Display Screen
Product Introduction
- Outdoor high resolution and high brightness, smallest pixel in the world 3.91mm.
- We supply high definiation video professor to realize the sigl source transition.
- Stable control system guarantees the events works well.
- Specially designed LED Electrical Control cabinet, which realizes the power supply for rental events anywhere
- suitable for stage rental, event show, concert, mobile advertising, etc.
Product parameters
|
Type Number
|
R391W-500H |
|
Dimension(MM)
|
500x500x85MM |
| Max.Power(w) | 200W |
| Cabinet Weight(KG) | 778KG |
| Refresh Rate (Hz) | 1920/3840H2 |
| Pixel Pitch(MM) | 391MM |
| LED Standard | SMD1921 |
| Scan Mode | 1/6Scan |
| Pixel Density(Dot/ni) | 65536Dot/m² |
| Brightness (CD/ni) | 4500CD/m² |
| Viewing Angle | 120° |
| Protection Leve | IP65 |
| Cabinet Material | Aluminum alloy |
| Maintenance ethod | Front Maintenance |
| Grey Level | 12-16 Bit |
| Working Temperature | -20-60C |
| Working Humidity | 1036-9036RH |
| Life Span | ≥50000 Hours |
| Refresh Rate(Hz) | AC 110W1220V.50/60H2 |
Product details
- GOLD-PLATEDCONNECTING SEAT
Using gold-plated connection seat, the signal is more stableFoolproof design to reduce installation error rate.
-
MULTIPLE SHAPES
The shape is changeable to meet the needs of more scenes and give users more choices.
-
FRONT -MAINTENANCE
Lock + magnetic fixation to improve safetyHidden module handle, single-person operation.
- Ingress protection being IP65, weather proof and dust proof.
- High brightness uniformity and color uniformity(≥95%)
- Super thin and light with die-casting aluminum cabinet design.
Company Profile
Charming Co., ltd has always been committed to technical innovation and service of global entertainmet lighting & LED.In 2003, the world's first led display was brought into the field of the entertainmnet applications, and contiunes to lead the trend of LED's in this field. It has developed into the first brand of customer satisfaction in China's entertainment lighting Led.It has obtained nearly 100 patents and obtained ISO9001, CE, CCC, CB, ROHS, SASO and other certifications.
What we offer to customer?
1.How can I get the price?-We usually quote within 24 hours after we get your inquiry.
-If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.
2. Can I buy samples placing orders?
-Yes.Please feel free to contact us.
3.What is your lead time?
-It depends on the order quantity and the season you place the order.
-Usually we can ship within 7-15 days for small quantity, and about 30 days for large quantity.
4.What is your payment term?
-T/T, Paypal, or other is ok .This is negotiable.
5.What is the shipping method?
-It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and ect).
Please confirm with us before placing orders.
