600~800 CD/㎡ Brightness Curved P1.9 P2.6 P2.98 P3.91 Video Led Display Wall Indoor Smd Led Rental Display Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Charming |
| Certification: | CE, ROHS, LVD, EMC, CB, BIS, UL |
| Model Number: | P3.91 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton Case, Wooden Case, Flight Case |
| Delivery Time: | 10 Working Days after Payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, Cash |
| Supply Ability: | 1000 PCS per week |
|
Detail Information |
|||
| Screen Resolution: | 128*128/128*256 | Cabinet Weight: | 6.6Kg/6.7Kg/10.8Kg |
|---|---|---|---|
| IP Grade: | IP42 | MaxPower: | 100/200W |
| Operation Temperature: | -20~40℃ | Life Span: | Over 50000 Hours |
| Pixel Density: | 65536 Dot/㎡ | Cabinet Size: | 500x500x86mm / 500x1000x86mm |
| Screen Brightness: | 600~800 CD/㎡ | ||
| Highlight: | Indoor Smd Led Display Wall,Rental Display Panel Led Display Wall |
||
Product Description
600~800 CD/㎡ Brightness Curved P1.9 P2.6 P2.98 P3.91 Video Led Display Wall Indoor Smd Led Rental Display Panel
Product introduce
1.Up and Down, Left and Right, Misaligned Splicing
2.Curved cabinet: Arc lock adjustable to ±10° , 36 pcs can be assembled into a cylinder
3.Magnetic suction installation, simple and quick maintenance for various installation environment, improve work efficiency
4.Compatible - the new structure designed to meet the lifting, stacking requirements to meet the indoor and outdoor requirements
Product Details
1.Flexible cabinet: Arc lock adjustable to ±22.5° , 8 pcs can be assembled into a cylinder
2.Hard Connection, HUB card design, Without Any Cables
3.Lightweight - weights only 6.6kg, single person can be a single portable, and extremely easy to install
4.Smd led display module & cabinet is manufactured by using best quality material,we make the module and cabinet by ourself
Product Parameters
|
Cabinet Type |
Flexible | Curved |
Ruglar |
|---|---|---|---|
|
Dimension(MM) |
500x500x84mm | 500x500x84 |
500x1000x84mm |
|
Max Power(W) |
100W | 100W |
200W |
|
Cabinet Weight(KG) |
6.7KG | 6.6KG |
10.8KG |
|
Refresh Rate(Hz) |
7680Hz | 7680Hz |
7680Hz |
|
Pixel Pitch(MM) |
3.91mm | ||
|
Led Standard |
SMD2020 |
||
|
Pixel Density(Dot/M²) |
65536 Dot/M² |
||
|
Brightness(CD/M²) |
600-800CD/M² |
||
|
Viewing Angle |
120° |
||
|
IP Rate |
IP42 |
||
|
Cabinet Material |
Aluminum Alloy |
||
|
Maintenance |
Front Service |
||
|
Grey Level |
14-16 bit |
||
|
Working Temperature |
20~60℃ |
||
|
Working Humidity |
10%~90%RH |
||
|
Life Span |
≥50000 Hours |
||
|
Working Voltage |
AC110V/220V | ||
Technology Training & Documents and Certification
We provide the technology training for free, which contains the operation training and maintenance training in the factory. We provide the operation manual, software, test report and so on.We can also provide all kinds of certification such as CE, UL and so on.
Company Introduction
Charming Co., ltd has always been committed to technical innovation and service of global entertainmet lighting & LED. In 2003, the world's first led display was brought into the field of the entertainmnet applications, and contiunes to lead the trend of LED's in this field. It has developed into the first brand of customer satisfaction in China's entertainment lighting Led. It has obtained nearly 100 patents and obtained ISO9001, CE, CCC, CB, ROHS, SASO and other certifications. Adhering to the corporate philosophy of " Charming Achieve Beauty ", we have an international standard full-automatic led display production line with a factory area of more than 10,000 sqm. We have provided quality products and services to customers in more than 150 countries and regions for 21 years.
Fastest Delivery and Best Online Services
Charming LED tech provides best online services to the customers.We are always ready to assist you when you need us. Also we take good care of the safety of the products. We work with the leading logistics who ensure fastest and safest delivery of your products.
Warranty
We guarantee all our displays, modules, parts for two full years. During this time, we will replace or amend all our goods for free if there is something wrong with them. We provide lifetime maintenance and charge only for the raw materials. We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory. We also provide the operation manual, software, test report and so on. Any associated CAD drawing on how to fix up the display and some other expert suggestion will be provided.
